Mars Global Surveyor: Fractures and Pits in the Northern Plains of West Utopia

Press Release From: Jet Propulsion Laboratory
Posted: Thursday, November 1, 2001

MGS MOC Release No. MOC2-293, 30 October 2001

Image with all annotation (785 KBytes)
Image with some annotation (785 KBytes)
Image with no annotation (800 KBytes)

In September 1976, NASA's Viking 2 lander touched down on a rocky plain in Utopia Planitia near 48.0°N, 225.7°W. Utopia is a vast and varied region. Nearly 1,700 kilometers (~1,060 miles) west of the Viking 2 site lies a pitted and fractured plain unlike anything found by the Mars Global Surveyor (MGS) Mars Orbiter Camera (MOC) elsewhere on Mars. Although the martian northern plains are often considered to be "flat" or "featureless," the MOC has shown that, at the scale of a few tens of meters (tens of yards), these plains aren't all flat, featureless, or even "boring". In the 2001 MOC image shown here, a suite of sharply-oulined pits and fractures indicate that the upper surface materials are strong and indurated (cemented). The parallel and polygonal alignments of fractures and pits indicate that this area has been subjected to directional stress--perhaps weaker but not unlike the stresses in the Earth's crust that cause faulting and earthquakes. The pits furthermore indicate that something has been removed from beneath the rigid, upper crusted material. Unfortunately, the image does not provide obvious or direct answers as to what the rigid, indurated upper surface is made of, nor the composition of the material underneath it that was removed to cause the pitting. Some Mars scientists have speculated that removal of ground ice could cause the pitting, but whether this is actually the case is unknown and cannot be known with any certainty from the photograph alone. Sunlight illuminates the scene from the lower left; the box at the upper right shows the location of the high resolution view in Utopia.

Image Credit: NASA/JPL/Malin Space Science Systems
